這款大承載旋轉臺配備200毫米直徑不銹鋼工作臺面，設計負載能力達700磅（約318公斤）。
其核心結構采用單套大載荷預緊交叉滾子軸承驅動工作臺運動，該設計摒棄了傳統雙軸承配置，從而顯著提升軸向跳動精度和抗偏擺性能。用戶可根據需求選配高性能伺服電機或步進電機驅動系統。
RM-8采用減速比為80:1的蝸輪傳動機構，通過預緊蝸桿有效降低齒輪傳動鏈背隙。另提供低溫版本可選，工作溫度范圍覆蓋-50°C至70°C極端環境。
Specifications
Resolution | 0.32 arc-sec (Stepper Motor) |
Accuracy | ±72 arc-sec |
Max. Speed | 20°/sec (Stepper Motor) |
Repeatability (uni-directional) | 5 arc-sec |
Bi-directional Repeatability | 45 arc-sec |
Max Load Capacity | 317 kg (700 lbs) |
Travel Range | 360° Continuous |
Encoder | Optical rotary encoder mounted to rear of motor, 4000 CPR with Index?(Optional) |
Limit Switches | None |
Origin | Inductive home switch (Optional)?Optical index mark on encoder (with encoder option) |
Gear Ratio | 80:1 |
Stage Weight | 13.6 kg (30 lbs) |
Material | Aluminum Alloy Construction |
Finish | Black Anodize |
