EASYHEAT 4.2、6.0、9.0及10千瓦 | 150-400千赫茲 系統
EASYHEAT 10系列 全能典范
♦ 多幾何形態高效加熱
♦ 敏捷頻率調諧實現可重復的穩定加熱
♦ 可移動工作頭最遠延伸3米
♦ 支持遠程串行操作與數據記錄（可選）
♦ 雙系統三語種顯示界面
♦ 具備現場校準功能
EASYHEAT 10系列 智能易用
♦ 自適應調節確保精準可重復結果
♦ 實時監測設定值、輸出功率、頻率與計時參數
♦ 集成定時器與秒表功能
♦ 一鍵式射頻功率控制
EASYHEAT 10系列 緊湊輕量
♦ 同功率等級中體積最小的全功能機型
EASYHEAT 4千瓦、6千瓦、9千瓦及10千瓦感應加熱系統，以快速潔凈的熱源為您提供可靠緊湊的部件加熱方案。可移動工作頭與電源最遠間距達3米，是實現可重復非接觸式加熱的理想選擇。
系統搭載寬頻工作范圍（150-400千赫茲），配合50W精度的功率控制，可勝任多種幾何形狀與材料構成的部件加熱任務。
通過單周期與連續加熱模式的靈活調諧，有效避免生產中斷。單套系統既能滿足釬焊所需深層體加熱，也可實現小零件表面淬火的精準局部加熱。無焰非接觸式加熱技術將能量精準聚焦于待加熱區域，最大限度提升能源利用率。前面板LCD顯示屏與密封觸摸板提供便捷的功率設置與監控，同時支持通過接觸輸入、模擬輸入或選配串行數據端口進行遠程功率控制。內置可編程數字計時器讓加熱周期調節得心應手。
本系列采用水冷設計，需連接熱交換器或冷卻裝置。
EASYHEAT配備前面板可編程控制器，支持創建四種獨立加熱方案，每種方案最多可設置五個時間/功率步驟。
選配件與附件
♦ 熱交換器或冷卻裝置
♦ 光學高溫計（閉環溫度控制）
♦ 外部PLC控制器
♦ 加長型工作頭電纜
♦ 腳踏開關
♦ 串行數據接口
♦ 懸掛式操作站
♦ 啟動輔助套件
EASYHEAT 4.2千瓦感應加熱系統、6.0千瓦感應加熱系統、EASYHEAT 3542感應加熱系統、EASYHEAT 5060感應加熱系統、EASYHEAT 7590感應加熱系統、EASYHEAT 8310感應加熱系統
| SPECIFICATION | VALUE | UNITS |
| RF Terminal Power | 4.2 | kW |
| AC Line Power | 5.2 | kVA |
| AC Line Protection1 | [35] 20 | A |
| Output Frequency | 150-400 | kHz |
| RF Coil Current | 300-750 | Amax |
| AC Line Voltage2 | [187-230 or 230-264] 370-440 or 440-520 | Vac |
| Display | LCD Monochrome, 240w x 128h pixels, 2 line x 16 character LCD; displays frequency, power, setpoint, timer and fault descriptions | |
| Display Language Suite3 | EN, FR, IT, DE, ES | |
| Serial Communications | Via RS485 terminal mode | Optional |
| Process Timer | 0.01 – 10000 | sec |
| Heating Controller | 4 programmable profiles, 5 steps per profile | |
| RF Rise Time | <5 | ms |
| Tune Time | <5 | ms |
| Compliance4 | CE & UKCA Marked, 440Vac models only | |
| Max Ambient Temp | 45 (115) | C° (F°) |
| Weight | 28 (50) | kg (lb) |
| Dimensions | 432x610x178 (17x24x7) | WxDxH mm (in) |
| WATER COOLING (Sys)5 | ||
| Flow | 3.8 (1.0) | l/m (g/m) |
| Max Input Pressure | 5.6 (80) | bar (lb/in2) |
| Pressure Differential | 2.8 – 5.5 (40-80) | bar (lb/in2) |
| Max Temp | Water: 35 (95) | C° (F°) |
| 1) AC line protection:? Line levels: [230 V] or 440 V 2) AC? line voltage: Level determined by model; range factory set per order; field selectable 3) Language suite: Factory set 4) Compliance:?Suitable for incorporation into equipment for compliance with Machinery Directive 5) Cooling: Includes workhead Download data sheet for more details | ||
| SPECIFICATION | VALUE | UNITS |
| RF Terminal Power | 6 | kW |
| AC Line Power | 7.4 | kVA |
| AC Line Protection1 | [35] 20 | A |
| Output Frequency | 150-400 | kHz |
| RF Coil Current | 300-750 | Amax |
| AC Line Voltage2 | [187-230 or 230-264] 370-440 or 440-520 | Vac |
| Display | LCD Monochrome, 240w x 128h pixels, 2 line x 16 character LCD; displays frequency, power, setpoint, timer and fault descriptions | |
| Display Language Suite3 | EN, FR, IT, DE, ES | |
| Serial Communications | Via RS485 terminal mode | Optional |
| Process Timer | 0.01 – 10000 | sec |
| Heating Controller | 4 programmable profiles, 5 steps per profile | |
| RF Rise Time | <5 | ms |
| Tune Time | <5 | ms |
| Compliance4 | CE & UKCA Marked, 440Vac models only | |
| Max Ambient Temp | 45 (115) | C° (F°) |
| Weight | 28 (50) | kg (lb) |
| Dimensions | 432x610x178 (17x24x7) | WxDxH mm (in) |
| WATER COOLING (Sys)5 | ||
| Flow | 5.7 (1.5) | l/m (g/m) |
| Max Input Pressure | 5.6 (80) | bar (lb/in2) |
| Pressure Differential | 2.8 – 5.5 (40-80) | bar (lb/in2) |
| Max Temp | Water: 35 (95) | C° (F°) |
| 1) AC line protection:? Line levels: [230 V] or 440 V 2) AC? line voltage: Level determined by model; range factory set per order; field selectable 3) Language suite: Factory set 4) Compliance:?Suitable for incorporation into equipment for compliance with Machinery Directive 5) Cooling: Includes workhead Download data sheet for more details | ||
